NJJ-300 battering machine

Product Description

Submersible pulping machine can immerse the product in the pulp, so that the product can be coated with a layer of tempura pulp. It is applicable to tempura products, poultry meat, seafood, vegetables and other products.

Tel.: +86-0536-6481966

NJJ-300 battering machine

Submersible pulping machine can immerse the product in the pulp, so that the product can be coated with a layer of tempura pulp. It is applicable to tempura products, poultry meat, seafood, vegetables and other products.
Tel.: +86-0536-6481966
Product Description

Submersible pulping machine can immerse the product in the pulp, so that the product can be coated with a layer of tempura pulp. It is applicable to tempura products, poultry meat, seafood, vegetables and other products.



The product is attached by the upper and lower net belt, and can be fully immersed and wrapped in the pulp;

The distance between the upper and lower net belts can be adjusted;

Even if the viscosity of the pulp is high, it is possible to ensure a smooth coating;

Control the pulp content of the product by adjusting the fan;

The transmission speed of the conveyor belt is controlled by frequency converter and the step-less speed regulation is implemented;

It is corrosion-resistant with stainless steel material. It may be dismantled with a special tool and cleaned thoroughly.

Technical parameters
Model NJJ200 NJJ300 NJJ400 NJJ600
Conveyer belt speed 8 m/min 3-15m/minute speed regulation
Power 0.62KW 0.45KW 1.3KW 2.2KW
Net belt width 200mm 300mm 400mm 600mm
Overall dimension 1390×550×1320mm 1880×650×1320mm 3020×880×1250mm 3020×1080×1250mm
Model  NJJ200
Conveyer belt speed 8 m/min
Power 0.62KW
Net belt width 200mm
Overall dimension 1390×550×1320mm
Model  NJJ300
Conveyer belt speed 3-15m/minute speed regulation
Power 0.45KW
Net belt width 300mm
Overall dimension 1880×650×1320mm
Model  NJJ400
Conveyer belt speed 3-15m/minute speed regulation
Power 1.3KW
Net belt width 400mm
Overall dimension 3020×880×1250mm
Model  NJJ600
Conveyer belt speed 3-15m/minute speed regulation
Power 2.2KW
Net belt width 600mm
Overall dimension 3020×1080×1250mm
Product Display
