FQJ2-160 cutting machine

Product Description

It can cut a piece of meat horizontally. It is suitable for slicing and processing of fresh raw materials such as pig, beef and other livestock meat, poultry meat and so on. Chicken breast of butterfly heart shape can be cut and processed.

Tel.: +86-0536-6481966
Your Position: Home » Product Display » Cutting equipment » Slicer

FQJ2-160 cutting machine

It can cut a piece of meat horizontally. It is suitable for slicing and processing of fresh raw materials such as pig, beef and other livestock meat, poultry meat and so on. Chicken breast of butterfly heart shape can be cut and processed.
Tel.: +86-0536-6481966
Product Description

Features of equipment:

The accurate cutting thickness can be up to 3mm, the multi-layer slicing is high in efficiency and can be up to 5 layers;

The thickness of the cutting product can be adjusted by replacing the tool holder; Chicken breast of butterfly heart shape can be cut and processed by replacing cutter;

The floating net belt design is suitable for different thickness of meat block, and can be designed into multiple layers of different thickness;

With dual channel operation, the output can reach 120 blocks /min;

Imported washboard belt of high service life is used;

It conforms to CE standard with SIEMENS electric parts and protective device;

Made of stainless steel and engineering plastics, it is easy to clean and in line with HACCP requirements;

The operation is convenient, and the maintenance cost is low.



Advantages of equipment:

The accuracy of cutting thickness is incomparable;

It can reduce the number of manual cutting, reduce labor costs, and achieve high efficiency;

It can be connected to slitting machine to produce the strip products of the same size.

Technical parameters

Net belt width

3-15m/min
(variable frequency speed control)

Cutting thickness

Min:3mm;Max:50mm

Cutting speed

120 blocks/ min
(dual channel)

Product width

140mm

Input/output height

1050±50mm

Net belt width

2×160mm

Power

1.65KW

Overall dimension

2100×1300×1200mm

Net belt width

3-15m/min
(variable frequency speed control)

Cutting thickness

Min:3mm;Max:50mm

Cutting speed

120 blocks/ min
(dual channel)

Product width

140mm

Input/output height

1050±50mm

Net belt width

2×160mm

Power

1.65KW

Overall dimension

2100×1300×1200mm
